PCB高频板

Taconic’s Advanced Dielectric Division is a world leader in RF laminates, prepregs and high speed digital and flexible interconnect materials utilized in some of the most cutting-edge communication systems in the world.

Taconic’s Industrial Products Division produces PTFE and silicone coated fabrics, tapes and belts for a wide range of industrial applications. These durable coatings offer a host of benefits that make them ideal for demanding environments.

For a comprehensive selection of RF Laminates and Prepregs.

1.Ceramic Filled PTFE Laminates offer enhanced thermal and electrical stability.

• • TLY-5Z

• RF-30A
• RF-30
• TLF-35A
• RF-35
• RF-35A2
• RF-41, RF-43, RF-45
• RF-60A
• RF-10

2.Woven Glass Reinforced PTFE Laminates contain fiberglass as a mechanical reinforcement for increased dimensional stability.

• TLY-5,TLY-5A
• TLX-6-7-8-9

Taconic TLY laminates are manufactured with very lightweight woven fiberglass and are more dimensionally stable than chopped fiber reinforced PTFE composites. The woven matrix yields a more mechanically stable laminate that is suitable for high volume manufacturing. The low dissipation factor enables successful deployment for automotive radar applications designed at 77 GHz as well as other antennas in millimeter wave frequencies.

  none

为满足高频板行业生产需求引进全套生产设备

世界顶级高频板料供应商的长期合作伙伴

  none

1、顶级高频材料资源，让您的产品赢在根本

☆世界顶级高频材料商Rogers/罗杰斯,taconic/泰康利, Arlon,Isola,F4BM/旺灵,PTFE/铁氟龙的长期战略合作伙伴

☆可为高频板行业客户提供最优质的材料与相关资源,从根本上控制产品品质

2、领先的工艺能力，满足高频PCB制板需求

☆最大厚径比10:1最大铜厚6OZ最大工作板尺寸2000x610mm

☆最薄4层板0.33mm最小机械孔/焊盘0.15/0.40mm

☆钻孔精度+/-0.05mmPTH孔径公差+/-0.05mm

☆最小线宽/线距3mil/0.075mm

☆成熟混压技术：FR4+ROGERS/罗杰斯,FR4+PTFE,FR4+408HR,陶瓷+FR4

  none

  none

3、先进的自动化生产设备及精密检验设备

☆专为高频板行业配备全套表面处理生产线

☆引进电脑V割机，德国压机，激光钻机，机械钻机，全自动曝光机、LDI、AOI

☆行业少数配备全套表面处理设备(沉金，沉银，沉锡，OSP，喷锡，镀金镀厚金，镀锡，镀银)，为您降低外包生产风险

4、严谨的品质控制系统，保证出货品质合格率100%

☆严格按照IPC标准管控，保证出货品质合格率100%

☆进口自动检测设备及温度循环检验设备，保证产品高可靠性和稳定性

☆严格执行品质PDCA流程，持续提升产品性能

5、绿色环保先锋，知名客户的信心之选

☆南杭电路获江苏省清洁生产认证企业、苏州市清洁生产企业、线路板行业绿色环保先进企业称号

☆华兴，Philips，华普瑞,OMRON,西门子等知名客户的一致选择

none
